3 Car Garage Apartment Plan 76374
Garage Apartment - Drive-Through RV Garage Plan + Bonus Room | Plan 76374
click for more images
Plan Pricing
** Please note that a PDF File is included with a 3 Set Order**
**All plans by this designer are being updated to IRC 2015 starting on March 13, 2023. This plan may be delayed by 4 business days before shipping.**
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Bonus Area: | 627 sq ft |
| Garage Area: | 1527 sq ft |
| Garage Type: | Detached |
| Garage Bays: | 3 |
| Foundation Types: | Slab |
| Exterior Walls: | 2x6 |
| House Width: | 42' |
| House Depth: | 42' |
| Number of Stories: | 2 |
| Max Ridge Height: | 25'9 from Front Door Floor Level |
| Primary Roof Pitch: | 0 |
| Roof Framing: | Unknown |
Plan Description
Drive-Through RV Garage Plan + Bonus Room
Are you looking for a detached garage plan for your motorhome or recreational vehicle? Drive-Through RV Garage Plan + Bonus Room 76374 is the perfect choice to store your RV and 2 standard-sized vehicles. Plus, the upper level bonus room adds 627 square feet. Use the bonus room for storage or turn it into an upper-level apartment. Simple design is beneficial for those who want to build quickly and economically. This versatile construction plan will add function and value to your property.
2-Story Drive-Through RV Garage Plan
Let's take a look at level one: the ground level. Firstly, level one includes parking for your family's regular vehicles. Dimensions in this section are 23'8 wide by 30'8 deep. Ceiling heights are 9’2 for the car section of the garage. Two car door sizes are 9' by 7'. Not only can you park your cars, but you can also use the garage as your workshop. Do you like woodworking? Drive-Through RV Garage Plan 76374 has abundant space along the back and the side walls so that you can install peg board and organize your tools. Be ready for any handyman or DIY project.
Secondly, the RV parking area measures 17' wide by 40'8 deep. RV section has 13'2 ceiling height, and the doors are 12' x 12'. Plus, the RV doors open on both the front and the back. Depending on the size of your property, you can drive in one side and out the other side. Talk about convenient! We know you are an excellent driver, but why not avoid backing up that RV when you can? Yes, the main floor is open space. Open all of the garage doors and bring in the breeze on a cool fall day. This construction design is bigger than your average man cave!
Second Floor Bonus Room
Let's take a look at level two: the bonus room level. Everyone knows that travelling takes money. To help out with cash, you can finish the bonus space upstairs. Turn it into an apartment, and rent it out. Use the money to fund your travel expenses. Another option, the renter could barter for time. For example, the tenant could care for your property in exchange for a reduced monthly payment. If you're not interested in being a landlord, simply outfit the future apartment and use it as a guest room. In any case, it will add value to your property.
Drive-Through RV Garage Plan 76374 is an excellent choice for the adventurer. The generous sheltered parking area will keep your motorhome in tip-top shape when you’re not on the road. Need to do a little maintenance? No problem because all of your tools are right there. Need to store sporting equipment and camping gear? Well, there is plenty of space for that too. In conclusion, this motorhome plan is a popular choice because it supports your lifestyle in so many ways.
