Plan Description
Tiny Ultra-Modern House Plan Under 500 Sq Ft - 1 Bed and 1 Bath Offer Compact Living
This tiny house has an ultra-modern design and a 480 square foot floor plan. A contemporary style micro house with plenty of windows for a home with a view. This tiny floor plan has all you need to survive in this home away from home. Built on the hillside in the country or on the point at the lake, this plan with covered front porch, kitchen space, living area, nicely sized bedroom, and a bathroom with a stand-up shower. Modern house plan for micro living.
What's Included?
Exterior Elevations: show the front, rear and sides of the house, including exterior materials, details and measurements.
Foundation Plans: All necessary notations and dimensions are included. (Foundation options will vary for each plan. If the home you want does not have the type of foundation you desire, contact Familyhomeplans.com of your plan.)
Interior Elevations: (call 1-800-235-5700 before ordering to confirm availability) show the specific details of cabinets (kitchen, bathroom). We suggest contacting local cabinet and fireplace distributors for sizes and styles.
Schematic Electrical Layouts: (call 1-800-235-5700 before ordering to confirm availability) show the suggested locations for switches, fixtures and outlets. These details may be shown on the floor plan or on a separate diagram.
Detailed Floor Plans: show the placement of interior walls and the dimensions for rooms, doors, windows, stairways, etc., of each level of the house.
