5 Car Garage Plan 69917

• PDF File: $300.00
• 1 Set: $250.00
• 5 Sets: $300.00
• Reproducible Set: $400.00
• CAD File: $650.00
  Single Build License issued on CAD File orders.

Need A Materials List?

It seems that this plan does not offer a stock materials list, but we can make one for you. Please call 1-800-482-0464, x403 to discuss further.
• Right Reading Reverse: $200.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
• Additional Sets: $50.00

Available Foundation Types:

• Not Applicable

Available Exterior Wall Types:

• 2x4: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Garage Area:	1875 sq ft
Garage Type:	Detached
Garage Bays:	5
Foundation Types:	Not Applicable
Exterior Walls:	2x4
House Width:	50'
House Depth:	50'
Number of Stories:	1
Max Ridge Height:	16'8 from Front Door Floor Level
Primary Roof Pitch:	8:12
Roof Framing:	Stick
Main Ceiling Height:	8'

5 Car Garage

Garage Plan 69917 with 5 Car Garage

1/4" scale floor plan (or plans), electrical and plumbing noted directly on plan(s) no mechanical layouts available.

1/4" scale front elevation

Rear page with 1/4" scale rear elevation, 1/8" scale side elevations and roof detail

No foundation design included. Due to the wide variety of soil conditions and various building practices, there is no way we could provide accurate drawings to cover all situations. A registered professional engineer should design the foundation for your specific lot. We believe something this important should not use generic drawings. Where we are located, most municipalities, FHA/VA, and all the builder warranty programs require the foundations to be designed by a registered structural engineer.

Standard detail page with electrical legends, typical building section, building code notes, etc.
