Specifications

  • 3 Car Garage
  • 40'0 Wide x 40'0 Deep
Available Foundation Types:
  • Slab

Plan Pricing

  • PDF File: $615.00
  • 1 Set: $240.00
  • 5 Sets plus PDF File: $405.00
  • CAD File: $695.00
  • CAD File Unlimited Build: $770.00
    Unlimited Build License issued on CAD File Unlimited Build orders.
  • Right Reading Reverse: $50.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $20.00
* prices shown w/o any discounts applied

Garage Plan 41370 | Order Code: 00WEB | Elevation

Reverse Plan


Garage Plan 41370 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Garage Plan 41370 | Order Code: 00WEB | Rear Elevation

Specifications

  • Garage Area: 1600
  • Garage Type: Attached
  • Garage Bays: 3
  • House Width: 40'0
  • House Depth: 40'0
  • Number of Stories: 1
  • Max Ridge Height: 20'5 from Front Door Floor Level
  • Primary Roof Pitch: 4:12
  • Roof Load: 25 psf
  • Roof Framing: Stick
  • Main Ceiling Height: 10'

Available Foundation Types:

  • Slab

Plan Pricing

  • PDF File: $615.00
  • 1 Set: $240.00 **
  • 5 Sets plus PDF File: $405.00
  • CAD File: $695.00
  • CAD File Unlimited Build: $770.00
    Unlimited Build License issued on CAD File Unlimited Build orders.
  • Right Reading Reverse: $50.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $20.00

** 1 Set order does not include a License-To-Build. For bidding purposes only. Customer can upgrade order within 90 days.

* prices shown w/o any discounts applied

Architectural Styles

Traditional

Traditional Style Garage Plan

This Traditional style garage design is perfect for housing any vehicle type. Fitting up to 9 cars, this garage plan is sure to meet any serious motorists needs. This garage features two shorter 9' high garage doors and one 12' tall garage door perfect for larger recreational vehicles.
